2526Radiator
1 Row Plastic Tank Aluminum Core

Radiator

CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road

  • OEM specified Plastic Tank-Aluminum Core Construction
  • Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
  • Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
  • Tubes - Welded Type or Latest Generation "B-Tube" Design
  • Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
  • 100% leak tested before leaving factory at 150% of operating pressure
  • Industry Best Packaging - "10 Foot Drop Test" Standard
  • Drop-in Fit
  • High Performance Transmission Cooler with special Built-in Turburlator, when applicable
  • All components are installed, torqued, & tested on Radiator during assembly
Bottom Hose Fitting (in): 1 5/8 Right (in)
Box Height (in): 5 4/16
Box Length (in): 28 1/2
Box Weight (lbs): 10
Box Width (in): 20 13/16
Core Length (in): 21 11/16 (in)
Core Material: Aluminum
Core Thickness (in): 1 1/4 (in)
Core Width (in): 17 1/4 (in)
Cross-flow/ Down-flow: Cross Flow
Hazardous Material: No
Inlet Length (in): 17 3/4
Inlet Width (in): 2 1/16
No. Of Rows: 1
Outlet Length (in): 17 3/4
Outlet Width (in): 2 1/16
Radiator Cap Supplied: No
Tank Material: Plastic
Tech Note: O.E.M. style Plastic tanks & Aluminum core;Manufactured with steel crimp strips to strengthen Radiator by 40% over O.E.
Top Hose Fitting (in): 1 5/8 Left (in)
Make Model Qualifiers Year
BMW 323i
  • Position: N/A
  • 2.5L L6 2494cc 152ci
 1997-1998
BMW 325i
  • Position: N/A
  • 2.5L L6 2494cc 152ci
 1992-1997
BMW 325is
  • Position: N/A
  • 2.5L L6 2494cc 152ci
 1992-1995
BMW 328i
  • Position: N/A
  • 2.8L L6 2793cc
 1996-1999
BMW 328is
  • Position: N/A
  • 2.8L L6 2793cc
 1996-1999
BMW M3
  • Position: N/A
  • 3.0L L6 2990cc
  • Coupe
  • Manual
 1994-1995
BMW M3
  • Position: N/A
  • 3.2L L6 3152cc
  • Coupe
  • Manual
 1996-1999

Interchange is provided as a reference. Please check part specifications to verify fit.
Reference NumberReference Name
17 11 1 469 179OEM
17 11 1 469 908OEM
17 11 1 728 908OEM
1841DPI
8011841APDI
BM3010105Partslink
CU1841SPI
